Floorplan - 2017 Winnebago View 24G
-
-
-
-
![](https://assets-cdn.interactcp.com/interactrv/images/unit_photo_20160708063307440199371.JPG.pagespeed.ce.KVMOg8NK_j.jpg)
-
Sleeps 5
-
2 Slides
-
Bunk Over Cab
-
26ft Long
-
Arrow, Tidewater, Honeycomb, Zinc
24G Floorplan
Specifications
Sleeps | 5 | Slides | 2 |
Length | 25 ft 7 in | Ext Width | 7 ft 6 in |
Ext Height | 11 ft 1 in | Int Height | 6 ft 8 in |
Interior Color | Arrow, Tidewater, Honeycomb, Zinc | Exterior Color | 2 Deluxe, 6 Full-Body Paint Choices |
Hitch Weight | 5000 lbs | GVWR | 11030 lbs |
Fresh Water Capacity | 31 gals | Grey Water Capacity | 40 gals |
Black Water Capacity | 36 gals | Furnace BTU | 20000 btu |
Generator | Cummins Onan MicroQuiet 3600 watt | Fuel Type | Diesel |
Engine | Mercedes-Benz 3.0L | Chassis | Sprinter |
Horsepower | 188 hp | Fuel Capacity | 26.4 gals |
Wheelbase | 170 in | Available Beds | Queen |
Refrigerator Type | Norcold Double Door with Freezer | Convection Cooking | Yes |
Cooktop Burners | 2 | Shower Size | 25.5" x 36" |
Number of Awnings | 1 | Axle Weight Front | 4410 lbs |
Axle Weight Rear | 7720 lbs | LP Tank Capacity | 13 |
Water Heater Capacity | 6 gal | Water Heater Type | 110 Volt |
AC BTU | 15000 btu | Basement Storage | 53 cu. ft. |
TV Info | 28" HDTV | Awning Info | 16' Powered with LED Lights |
Gross Combined Weight | 15250 lbs | VIN | 8BNPF4CC8GE128591 |
Description
Take to the road in this Winnebago View class C diesel coach and know that you will have everything you need to enjoy spending time away from home. Model 24G features double slides for added space, a rear bedroom, and sleeping for four or five.
Step inside and enjoy a slide out booth dinette straight ahead for meals, or just for hanging out. You can also choose an optional TrueComfort+ sofa with table if you like instead. Above the cab area you can also add the optional 49" x 75" bunk for more sleeping space if needed for overnight guests.
The kitchen area is to the left of the entry door and features a double sink, a two burner cook-top, and refrigerator. You will also find plenty of overhead cabinets for storage too. Above the sink area is where you will find a 28" HDTV for viewing when seated at the dinette opposite.
Beyond the dinette and heading toward the rear of the coach you will find a side aisle bath with a shower, toilet, and a unique swivel sink. A nice size wardrobe is found just around the corner from the bath along the curb side wall next to the refrigerator before you step into the bedroom floor area.
The rear bedroom in model 24G features a slide out rear queen sized bed with overhead storage cabinets for your things. There is also a spot to mount an optional flat screen 24" HDTV in the bedroom just off the foot of the bed along the wall.
Why not enjoy this Winnebago View class C diesel on your next adventure!
Features
Mercedes-Benz® Sprinter Chassis
- 3.0L 6-cylinder, 188-hp, turbo-diesel engine, 5-speed automatic tip-shift transmission, 220-amp. alternator
- Adaptive ESP® technology
- Hydraulic brakes w/ABS
- Trailer Hitch 5,000-lb. drawbar/500-lb. maximum vertical tongue weight w/7-pin connector
- Stainless steel wheel liners (24J, 24V)
- ALCOA forged aluminum wheels (24G)
Options
- Stylized chrome wheels (24J, 24V)
- ALCOA forged aluminum wheels (24J, 24V)
- 2-point electric stabilizing system (Requires ALCOA forged aluminum wheels)
Cab Conveniences
- Radio/Rearview Monitor System DVD receiver with 6.2" LCD color touch screen, handheld remote, iPod®/MP3 input, rear color camera, Bluetooth®, SiriusXM®-ready, Spotify®, AppRadio One
- Cab seats armrest, adjustable lumbar support, headrest, recline, swivel and slide
- Airbags driver and passenger
- 3-point seat belts
- Power door locks w/remote
- Power windows
- Power mirrors w/defrost and turn signals
- Cruise control
- Chassis/house battery radio power switch
- Power steering w/tilt wheel
- Sunvisors
- 12-volt powerpoints
- Pleated windshield blinds
- Privacy curtain (cab windows)
- Dash appliqué package
Options
- Large Screen Infotainment Center with Rand McNally RV GPS 9" touch screen color monitor w/split screen function, Rand McNally RV GPS safe & easy routing, amenities & tools, trips & content, turn-by-turn voice guidance, AM/FM radio w/CD/DVD player, handheld remote, SiriusXM™ (subscription not included), iPod/iPhone® audio integration, Bluetooth™, color rearview camera, USB connection
- 2 cab seat lounge cushions
- Sliding, pleated windshield blinds
- Mobileye® Collision Avoidance System
- JBL premium audio tuned 180-watt DSP amplifier with 5 speakers including subwoofer
Interior
- Stereo System AM/FM, alarm clock, CD/DVD player, input jack, Bluetooth™, 2 speakers and subwoofer
- 28" HDTV
- LED lights
- Satellite system ready
- Monitor panel
- Amplified digital HDTV antenna
- Roof vent w/electric lift and ventilator fan (NA w/available powered skylight)
- Mini blinds (galley)
- Skylight w/shade
- MCD solar/blackout roller shades
- Tinted coach windows
- Soft vinyl ceiling
- Vinyl flooring throughout (24G front to bedroom)
- Assist bar
- Mirror (24V)
- USB charger
- Interior Upgrade Package frosted galley backsplash w/accent lighting, 2 sink covers
- Powered skylight/roof vent w/sliding screen and pleated shade
- Dual-pane acrylic windows
- Sofa sleeper (24G)
Galley
- Laminate countertops
- Microwave/convection oven w/touch control
- 2-burner range top w/glass cover
- Norcold® double-door refrigerator/freezer
- Cold water filtration system
- Water-pump switch w/light
Bath
- Shower 25.5"x36" (24G)
- Shower 26"x30" (24J)
- Shower 19"x28"x34" (24V)
- Retractable, self-cleaning shower screen
- Shower light w/wall switch
- Flexible showerhead
- Shower Skylight (24G includes molded track for LED rope light)
- Porcelain toilet w/foot pedal and sprayer (24J, 24V)
- Porcelain toilet w/electric flush (24G)
- Powered roof vent
- Towel ring(s)
- Towel bar(s)
- Tissue holder
- Robe hook(s) (24J)
- Medicine cabinet
- Powered ventilator fan
Bedroom
- Corner bed w/headboard, foam mattress, mattress cover, and access to storage below (24J)
- Queen bed w/memory foam mattress and mattress cover (24G)
- Flex Bed System twin beds/queen bed w/foam mattresses and access to storage below (24V)
- MCD blackout roller shades
- Room divider curtain (NA 24G)
Options
- 24" HDTV
- Froli deluxe sleep system (NA 24G)
Exterior
- Automatic entrance door step(s)
- LED porch light w/interior switch
- Stepwell light w/interior switch
- Front and rear mud flaps
- Premium high-gloss skin
- Powered patio awning w/LED lights (full-body paint option includes metal wrap)
- Lighted storage compartments
- Exterior speakers
- Ladder (NA 24G)
- Bike rack
Heating & Cooling System
- 15,000 BTU roof-mounted air conditioner
- 20,000 BTU low-profile furnace
- 15,000 BTU roof-mounted air conditioner w/heat pump
- Service Center light, cable TV input, 30-amp. power cord, portable satellite dish hookup, QuickPort® service connection hatch
- Auxiliary start circuit
- Exterior AC duplex
- Exterior antenna jack
- Battery disconnect system (coach)
- Automatic dual-battery charge control
- AC/DC load center, 45-amp. converter/charger
- 2 deep-cycle, Group 24 RV batteries
- 3,600-watt Cummins Onan MicroQuiet™ LP generator
- 1,000-watt DC/AC inverter
- 3,200-watt Cummins Onan® diesel generator
- 100-watt solar panel/battery charger w/controller, junction box, and plug for additional portable solar panel
- Service Center color-coded labels, pressurized city water hookup/tank diverter valve, drainage valves, exterior wash station w/lighted pump switch
- 10' sewer hose
- TrueLevel™ holding tank monitoring system
- 6-gallon 110-volt/LP water heater w/Energy Management System (NA 24G)
- Tankless water heater (24G)
- Permanent-mount LP Tank w/remote fill w/power switches
- Winterization Package water heater bypass valve and siphon tube
- On-demand water pump
- Lockable water tank fill
- Sewage pump macerator (NA 24J)
- Holding tank flushing system
Options
- Heated drainage system
- Tankless water heater (24J, 24V)
- LP, smoke and carbon monoxide detectors
- 10 BC fire extinguisher
- Ground fault interrupter
- Child seat tether anchor (NA 24V)
- High-mount brake lamps
- Daytime running lamps
